QPG6200L
Low-Power Multi-standard Wireless SoC
Production >
Please contact Qorvo Sales for details.
Key Features
- Multi-standard MatterTM, Thread, Zigbee and Bluetooth® Low Energy SoC
- Powered by ConcurrentConnectTM for superior RF performance:
- Multi-Channel enables Zigbee + Matter concurrently
- Antenna Diversity doubles the range
- Multi-Radio enables BLE scanning + Matter concurrently
- Best-in-class energy efficiency for multi-standard applications
- Industry-standard security with PSA Certified level 2
- Optimized design BOM with 4x4 QFN32 package and 2-layer PCB support
- Arm Cortex®-M4F up to 192 MHz with 2 MB NVM and 336 kB RAM
- Tx Power up to 10 dBm
The QPG6200L is the industry’s most reliable and robust wireless multi-standard System-on-Chip. Featuring Qorvo’s ConcurrentConnect™ technology, the QPG6200L supports the latest standards for Matter (over Thread), Zigbee and Bluetooth® Low Energy in a truly concurrent way.
The low-power QPG6200L enables the adoption of Matter while supporting existing Zigbee networks without tradeoffs in latency and link performance. It features ConcurrentConnect™ Technologies:
- Multi-Channel capability allows operating in up to 3 IEEE 802.15.4 PANs on different channels enabling Zigbee and Matter on separate channels ensuring RF performance.
- Antenna Diversity for Bluetooth Low Energy and IEEE 802.15.4 enables increased effective range and interference robustness.
- Multi-Radio capability allows continuously scanning for incoming packets across Bluetooth Low Energy and IEEE 802.15.4 protocols with no observable blind spots.
The IoT Dev Kit for QPG6200L (QPG6200LDK-01) provides a complete solution for building applications for connected devices with QPG6200L
Typical Applications
- Connected Lighting
- Smart Sensors
- Wearables
- Gateways
Product Categories
Application Categories
| Application | Connected Lighting, Smart Sensors, Wearables, Gateways |
| Protocols | Matter, Thread, Zigbee, Bluetooth Low Energy |
| ConcurrentConnect Technologies | Multi-Channel, Multi-Radio, Antenna Diversity |
| Max Tx Power(dBm) | 10 |
| Rx Sensitivity(dBm) | -101 (802.15.4), -97 (BLE @ 1Mbps) |
| Tx Current(mA) | 21 @ 10 dBm |
| Rx Current(mA) | 1.3 (802.15.4), 2.2 (BLE) |
| Sleep Current(uA) | At 32kB RAM retained: 0.9uA with LjRC Oscillator, 1.2uA with external 32KiHz Xtal Oscillator |
| MCU | Cortex-M4F with DSP, 192 MHz max |
| NVM Size(kB) | 2,048 |
| RAM Size(kB) | 336 |
| Security | PSACertified Level 2 leveraging secure element |
| GPIOs | 21 GPIO + 2 ANIO |
| Package Type | QFN, 32-pin |
| Package(mm) | 4.0 x 4.0 |
| RoHS | Yes |
| Lead Free | Yes |
| Halogen Free | Yes |
| ITAR Restricted | No |
| ECCN | EAR99 |
