DC-24 GHz (L, S, C, X, Ku, K Band) Distributed Driver Amplifier MMIC

    Key Features

    • High output power
    • Low noise figure
    • Positive gain slope
    • Small die size
    • Ultra wideband performance

    Qorvo's CMD244 is wideband GaAs MMIC distributed amplifier die which operates from DC to 24 GHz. The amplifier delivers 18 dB of gain with a corresponding output of 1 dB compression point of +25 dBm and noise figure of 2.5 dB at 10 GHz. The CMD244 is a 50 ohm matched design which eliminates the need for RF port matching. The CMD244 distributed amplifier also offers full passivation for increased reliability and moisture protection. This amplifier is the perfect alternative to higher cost hybrid devices.

    Typical Applications

      • Electronic Warfare (EW)
      • Radar
      • Space
      • Satellite Communications (Satcom)
      • Test & Measurement
    Frequency Min(GHz) DC
    Frequency Max(GHz) 24
    Gain(dB) 18
    NF(dB) 2.5
    OP1dB(dBm) 25
    Psat(dBm) 26.5
    OIP3(dBm) 32
    Vd(V) 5 to 8
    Vg(V) -0.65
    Current(mA) 185
    Package Type Die
    RoHS Yes
    Lead Free Yes
    Halogen Free Yes
    ITAR Restricted No
    ECCN EAR99

    Keysight Model Library

    This product is included in our Keysight PathWave System Design (SystemVue) and PathWave RF Synthesis (Genesys) compatible component libraries.
