Low Power IoT
Qorvo's innovative ultra-low-power wireless solutions comprising silicon, development kits, software, tools and reference designs enable smart home applications and the Internet of Things (IoT). They are optimized for smart lighting, remote controls, smart home gateways, and end devices, each with their specific features and needs. The silicon combines ultra-low-power features with best-in-class range and high reliability for full home coverage. Qorvo solutions feature ConcurrentConnect™ technology, a unique capability that provides simultaneous operations of single and multi-protocol smart devices over a single home network.
To use our IoT development calculators on our Design hub click here:
Matter
The QPG6200L offers an optimized, easy-to-use and certified solution for Matter devices while also supporting established low-power standards using ConcurrentConnect technology for superior radio performance. The QPG7015M also leverages ConcurrentConnect technology, ideal for gateway applications running Matter, Thread border router and Bluetooth Low Energy.
Learn More About ConcurrentConnect Technology
- Watch the Video and the Smart Lighting Demo
- Read the White Paper
- Connect with a Sales Representative
Visit the Matter Tech Forum and join the conversation.
Matter / Thread / Zigbee / Bluetooth® LE SoCs (7)
|
|
Low-Power Multi-standard Wireless SoC
|
Connected Lighting, Smart Sensors, Wearables, Gateways
|
Matter, Thread, Zigbee and Bluetooth Low Energy
|
Multi-channel, Multi-radio, Antenna Diversity
|
20
|
-101 (802.15.4), -97 (BLE @ 1Mbps)
|
117 @ +20 dBm 19 @ +10 dBm 7 @ +0 dBm
|
1.3 (802.15.4), 2.2 (BLE)
|
At 32kB RAM retained: 0.9uA with LjRC Oscillator, 0.76uA with external 32KiHz Xtal Oscillator
|
Cortex-M4F with DSP, up to 192 MHz clock speed
|
2,048
|
336
|
PSACertified Level 2 leveraging secure element
|
20 GPIO + 2 ANIO
|
|
QFN32 4.0 x 4.0 mm
|
|
|
Low-Power Multi-standard Wireless SoC
|
Connected Lighting, Smart Sensors, Wearables, Gateways
|
Matter, Thread, Zigbee and Bluetooth Low Energy
|
Multi-channel, Multi-radio, Antenna Diversity
|
20
|
-101 (802.15.4), -97 (BLE @ 1Mbps)
|
117 @ +20 dBm 19 @ +10 dBm 7 @ +0 dBm
|
1.3 (802.15.4), 2.2 (BLE)
|
At 32kB RAM retained: 0.9uA with LjRC Oscillator, 0.76uA with external 32KiHz Xtal Oscillator
|
Cortex-M4F with DSP, upto 192 MHz clock speed
|
2,048
|
336
|
PSACertified Level 2 leveraging secure element
|
28 GPIO + 4 ANIO
|
QFN40
|
5.0 x 5.0 mm
|
|
|
Low-Power Multi-standard Wireless SoC
|
Connected Lighting, Smart Sensors, Wearables, Gateways
|
Matter, Thread, Zigbee and Bluetooth Low Energy
|
Multi-channel, Multi-radio, Antenna Diversity
|
10
|
-101 (802.15.4), -97 (BLE @ 1Mbps)
|
19 @ +10 dBm 7 @ +0 dBm
|
1.3 (802.15.4), 2.2 (BLE)
|
At 32kB RAM retained: 0.9uA with LjRC Oscillator, 0.76uA with external 32KiHz Xtal Oscillator
|
Cortex-M4F with DSP, upto 192 MHz clock speed
|
2,048
|
336
|
PSACertified Level 2 leveraging secure element
|
29 GPIO + 4 ANIO
|
|
QFN40 5.0 x 5.0 mm
|
|
IEEE 802.15.4 / Bluetooth® Low Energy General Purpose Communication Controller
|
Electronic Shelf Labels and Generic 802.15.4/Bluetooth® Low Energy Connectivity Controller
|
IEEE 802.15.4 compliant PHY and Real-Time MAC & Bluetooth 4.2
|
Antenna Diversity
|
8
|
-100 (802.15.4), -96 (BLE @ 1Mbps)
|
17.9 @ 8 dBm
|
4.0 (802.15.4), 8.3 (BLE)
|
1.1 to 1.2
|
Arm Cortex-M4 with DSP
|
256 or 512
|
32 or 64
|
Hardware Accelerated Encryption
|
30 GPIO + 6 ANI
|
QFN, 40-pin
|
6.0 x 6.0
|
|
|
Zigbee® / Thread / Bluetooth® Low Energy Smart Home Communications Controller
|
Smart Home Devices
|
802.15.4, Zigbee 3.0, Zigbee Green Power, Thread, Bluetooth® Low Energy
|
Multi-Channel, Antenna Diversity
|
10
|
-100 (802.15.4), -97 (BLE @ 1Mbps)
|
23.6 @ 10 dBm
|
4.0 (802.15.4), 8.3 (BLE)
|
1.1 to 1.2
|
Arm Cortex-M4 with DSP
|
512
|
64
|
Hardware Accelerated Encryption
|
30 GPIO + 6 ANI
|
QFN, 40-pin
|
6.0 x 6.0
|
|
|
Multi-Standard Smart Home Communications Controller
|
Connected Lighting, Sensors, Smart Home Controllers
|
Zigbee, Thread, Matter, Bluetooth Low Energy
|
Multi-Channel, Multi-Radio, Antenna Diversity
|
10
|
-101 (802.15.4), -97 (BLE @ 1Mbps)
|
38.8 @ 10 dBm
|
5.6 (802.15.4), 10.4 (BLE)
|
1.3 to 2.0
|
Arm Cortex-M4 with DSP, 64 MHz max
|
1,024
|
128
|
Advanced Security Engine, Secure Boot, Secure OTA Update
|
23 GPIO + 4 ANI
|
QFN, 32-pin
|
4.0 x 4.0
|
|
|
Low-Power Multi-standard Wireless SoC
|
Connected Lighting, Smart Sensors, Wearables, Gateways
|
Matter, Thread, Zigbee, Bluetooth Low Energy
|
Multi-Channel, Multi-Radio, Antenna Diversity
|
10
|
-101 (802.15.4), -97 (BLE @ 1Mbps)
|
21 @ 10 dBm
|
1.3 (802.15.4), 2.2 (BLE)
|
At 32kB RAM retained: 0.9uA with LjRC Oscillator, 1.2uA with external 32KiHz Xtal Oscillator
|
Cortex-M4F with DSP, 192 MHz max
|
2,048
|
336
|
PSACertified Level 2 leveraging secure element
|
21 GPIO + 2 ANIO
|
QFN, 32-pin
|
4.0 x 4.0
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|---|
|
|
|
|
|
|
|
7 Matching Products
(7 total)
Add/Remove Parameters |
|---|
Add/Remove Parameters
Matter / Thread / Zigbee / Bluetooth® LE Transceivers (3)
|
IEEE 802.15.4 Communications Controller
|
Remote Control
|
802.15.4, Zigbee rf4ce
|
No
|
No
|
QFN, 24-pin
|
4.0 x 4.0
|
|
|
IEEE 802.15.4 Multi-Stack Multi-Channel Communications Controller
|
Smart Home Gateways
|
802.15.4, Zigbee® 3.0, Zigbee® rf4ce, Zigbee® GreenPower, OpenThread
|
Yes
|
Yes
|
QFN, 24-pin
|
4.0 x 4.0
|
|
|
Combo Zigbee®, Thread, Bluetooth® Low Energy 5.0, Multi-Stack, Multi-Channel Communication Controller
|
Gateways
|
Zigbee, Thread, Bluetooth® Low Energy
|
Yes
|
Yes
|
QFN, 32-pin
|
4.0 x 4.0
|
|
|
|
|
|
|
|
|
|---|
|
3 Matching Products
(3 total)
Add/Remove Parameters |
|---|
Add/Remove Parameters
Matter / Thread / Zigbee / Bluetooth® LE Development Kits (1)
|
IoT Dev Kit for QPG6200L
|
QPG6200L
|
One IoT carrier board, one QPG6200L radio board, USB cable
|
|
|
|
|
|---|
|
1 Matching Products
(1 total)
