QM35825DK-05
Linux® DevKit for QM35825 UWB
Key Features
- Secure ranging (distance between 2 UWB devices)
- PDoA (angle between 2 UWB devices)
- Radar (scanning nearby environment)
The Linux UWB Dev Kit for QM35825 enables to quickly discover the world of UltraWideBand, especially the ranging & radar capabilities. Without any prior experience, you will discover UWB, prototype & develop application through the “Getting Started Guide”.
The Qorvo Explorer App (GUI) demonstrates quickly the capabilities of the QM35825 device:
- Precise measurement of the distance between 2 UWB devices (± 5 cm accuracy)
- Direction of other UWB device (± 2° angle accuracy)
- Radar scanning of nearby environment (presence detection – are you nearby the sensor?)
The UQT python tool enables the development of your own script based on the ranging & radar API stack provided by Qorvo (Fira3.0 certified). The “Getting Start Guide” explains how UWB ranging accurately tracks the position and the movement of a UWB device.
The SDK will demonstrate how to write applications under Linux® based on the the Qorvo stack (Fira3.0 certified). This application written in C/C++ is executed on the Raspberry PI 4 integrated to the kit. The “Getting Start Guide” explains how UWB ranging accurately tracks the position and the movement of a UWB device.
Typical Applications
- Secure identification & logical access (payment console, barcode readers, laptops)
- Geofencing for safety and security
- Radar for motion detection, vital sign monitoring, people counting, gesture detection/recognition
- Consumer IoT, home entertainment
- Enhanced user experience with Location Aware Sensing based on FiRa 3.0 (TV and Air Mouse, Speakers, and Smart Thermostats)
- Hands-free door lock access (based on CCC/Aliro specification)
Product Categories
Application Categories
| Based On | QM35825 |
| Contents | 2 USB Type-C cables and 2 modules, RaspberryPI4 8GB, interface board, UWB QM35825 radio board, “Jolie Quad” Qorvo antenna & stand, PC interface board, UWB QM35825 radio board, “Jolie Quad” Qorvo antenna & stand |
| RoHS | Yes |
| Lead Free | Yes |
| Halogen Free | Yes |
| ITAR Restricted | No |
| ECCN | EAR99 |
