QPL9095

    Ultra Low-Noise Bypass LNA

    Key Features

    • 0.5 – 1.0 GHz Operational Bandwidth
    • LNA with Integrated Bypass Mode
    • Ability to turn LNA and Bypass Mode OFF
    • Ultra Low Noise Figure, 0.6 dB at 0.9 GHz
    • 22 dB Gain at 0.9 GHz
    • 34 dBm OIP3 at 0.9 GHz
    • Internally Matched
    • Positive supply only, 3.3 - 5 V


    The QPL9095 is a high-linearity, ultra-low noise gain block amplifier with a bypass mode functionality integrated in the product. At 900MHz, the amplifier typically provides 22 dB gain, +34 dBm OIP3, and 0.6 dB noise figure while drawing 50 mA current from a +4.2 V supply. The QPL9095 is internally matched using a high performance E-pHEMT process and only requires four external components for operation from a single positive supply: an external RF choke and blocking/bypass capacitors. This low noise amplifier contains an internal active bias to maintain high performance over temperature.

    The QPL9095 is optimized for the 500MHz – 1000MHz frequency band and is targeted for wireless infrastructure. The QPL9095 is packaged in a 2 x 2 mm DFN.



    Typical Applications

      • Base Station Receivers
      • Tower Mount Amplifiers
      • Repeaters
      • FDD-LTE, TDD-LTE, WCDMA
      • General Purpose Wireless

    Frequency Min(GHz) 0.6
    Frequency Max(GHz) 1
    Gain(dB) 22
    NF(dB) 0.6
    OP1dB(dBm) 20
    OIP3(dBm) 34
    Voltage(V) 4.2
    Current(mA) 55
    Package Type DFN
    Package(mm) 2.0 X 2.0
    RoHS Yes
    Lead Free Yes
    Halogen Free Yes
    ITAR Restricted No

    This product appears in the following application block diagrams:

    • Applications > Network Infrastructure > Wireless Infrastructure > Cellular Infrastructure Base Station

      Cellular Infrastructure Base Station

    • Applications > Network Infrastructure > Wireless Infrastructure > Repeaters / Boosters / DAS

      Repeaters / Boosters / DAS

    • Applications > Network Infrastructure > Wireless Infrastructure > Small Cells FDD

      Small Cells FDD

    • Applications > Network Infrastructure > Wireless Infrastructure > Small Cells TDD

      Small Cells TDD
